Robland HX 310 Combination Machine

  • Robland HX 310 Combination Machine

    Robland HX 310 Combination Machine robland-hx310-pro

    The Robland HX Pro is a quality European made Combination Woodworking Machine with Table Saw, Spindle Moulder, Planer & Thicknesser and optional Morticer. Saw blade diameter of 250mm with maximum cutting depth of 85mm, 30mm spindle arbour with a 120mm capacity and a maximum thicknesser capacity of 230mm.

    Price from $12,000 inc. gst

    Robland HX 310 Pro Specifications:

    • Motor power: 4 PS/hp (S6)
    • Blade diameter & bore: 250x30mm, RPM: 4,500
    • Cutting depth at 90°: 85mm, depth at 45°: 55mm
    • Dimensions cast iron table: 1077x273mm
    • Length sliding table: 1,250mm (option 2050mm)
    • Cutting length: 1,450mm (option 2100mm)
    • Width of sliding table: 320mm
    • Spindle length: 180mm
    • Cutting width parallel fence: 640mm
    • Spindle speeds: 3000/4500/6000/7000/10000 RPM
    • Max. diameter & height of table opening: 320x95mm
    • Weight (TS/TL/TP): 560/655/1070kg
    • RPM 3-phase: 3,000/6000, RPM single phase: 6000
    • Diameter spindle arbour: 30mm (option 50mm)
    • Spindle arbour capacity: 120mm
    • Travel: 140mm, table opening: 180mm
    • Motor power: 4 PS/hp (S6)
    • Total length planer tables: 1,230mm
    • Capacity thicknesser: 230mm
    • Cutter block diameter: 70mm, Knives: 3
    • Knife dimensions: 310x25x3mm
    • Feeding speed: 6m/min, RPM: 5,500
    • Motor power: 4 PS/hp (S6)
    MORTICER (Option)
    • Chuck: 0 to 16mmmm
    • Travel: 165x140x85mm
    Specifications (other):
    • Power: 3-phase or 240V option
    • Dust outlets: 100mm
    • Weight (net): 539kg
